* No process for end curving is require.
* It rolls iron sheet accurately by one process.
* High productivity and simple operation.
* No operation pressure and table height adjustment.
* It never brings about break and bend even if the
sheet has holes and notches, embosses
..on
its surface.
* It never crack and flaw even if the sheet has
patterns and luster on its surface.
* Adjustable operation pressure in rolling process.
* Longitudinal butt welding is easy to process. |
|
| |
|
 |
|
|
- Muffler
- Boiler tank
- Motor case
- Pump housing
- Gas bottle
- Thermos bottle
- L.P.G Bombe
- Fire extinguisher
- Transformer tank
- Chimney pipe
- Industrial chimney
- Washing machine vat
|
- Music drums
- Water heater
- Water filter
- Ventilation pipe
- Tractor wheel
- Air bag tubes in car
- Truck oil tank
- Truck exhaust pipe
- Ashtray (Airport)
- Dustbin
- Body for Air Conditioning compressor
- Compressed air tank for Truck braking system
|
|
|
|
|
 |
| ITEM
/ MODEL |
URH-600 |
| Input
Voltage Spec. |
AC
220V/380V , 50/60Hz, ©ª3, ¡¾10% |
|
Steel Roll Out diameter |
©ª80
- ©ª130 |
| Rolling
Motor |
1.5Kw
, 4p |
| Rolling
Speed |
6.0
m/min |
| Hydraulic
Pressure |
140
kgf/§² |
| Hydraulic
Motor |
1.5
Kw , 4p |
| Dimension
(mm) |
Width |
1,130 |
| |
Depth |
890 |
| |
Height |
1,045 |
| Weight
(kg) |
1,100 |
|
|
| |
 |
| Model/Spec |
Thickness
(mm)
|
Length
(mm) |
Rolling
Speed(m/min) |
Motor(kw) |
| URH-450 |
2.3t |
450mm |
6.0m/min |
1.5kw(2HP) |
| URH-600 |
1.6t |
600mm |
6.0m/min |
1.5kw(2HP) |
| URH-800 |
3.2t |
800mm |
6.0m/min |
2.2kw(3HP) |
| URH-1000 |
2.3t |
1,000mm |
6.0m/min |
2.2kw(3HP) |
| URH-1200 |
3.2t |
1,200mm |
3.5m/min |
3.7kw(5HP) |
| URH-1600 |
4.5t |
1,600mm |
3.5m/min |
7.5kw(10HP) |
|
| |
| |
|
| |
| |
|  |
| |
| |
|
|
| * We make possible for your
company's request specification. |
| * Above specification is subject
to change without notice for improvement |
|
| |
|
|
|
